Description
Overview & Key Specifications
Composition & Structure
-
Material: Monofilament polypropylene
-
Construction: Knitted into a thin, elastic, shape‑stable mesh to adapt both longitudinally and laterally to tissue movement
-
Biostability: The mesh is non‑degradable after implantation and holds its structure over time
Physical Properties (from brochure data)
-
Weight: Approximately 82 g/m² Thickness: ~0.48 mm
-
Pore Size: ~0.8 mm
-
Flexural Rigidity (ASTM D 1388‑64): Indicative curve suggests around 185–300 mg·cm, compared to conventional meshes around 400–600 mg·cm; emphasizes a more flexible construction
Handling & Performance Features
-
Transparency: Highly transparent mesh enabling visibility of underlying tissue during surgery
-
Laser‑cut Edges: Edges are sealed via laser during cutting to prevent fraying
-
Adaptability: Maintains dimensional stability; conforms well to body motion and is suitable for open and laparoscopic procedures
Indications
-
Designed for reinforcement in various hernia repairs:
-
Inguinal hernia
-
Primary ventral hernia
-
Incisional hernia
-
Prophylactic use to prevent incisional hernia in high-risk patients (based on clinical criteria like age, BMI, comorbidities)
-
Sterilization & Contraindications
-
Sterilization method: Ethylene oxide
-
Contraindications: Not to be used in contaminated or infected surgical sites or in pediatric patients during growth phase
Available Sizes
According to the product brochure, available in multiple dimensions (each pack contains 5 units)
Article No. | Dimensions (cm) |
---|---|
1064305 | 3 × 10 |
1064315 | 5 × 10 |
1064325 | 4.5 × 9.5 |
1064335 | 6 × 12.5 |
1064345 | 4.5 × 10 |
1064365 | 6 × 14 |
1064375 | 6 × 14 (duplicate?) |
1064385 | 4.5 × 10 |
1064415 | 7.5 × 7.5 |
1064425 | 7.5 × 15 |
1064435 | 15 × 15 |
1064445 | 5 × 30 |
1064455 | 30 × 30 |
1064465 | 26 × 36 |
1064495 | 10 × 15 |
Summary Table
Feature | Specification |
---|---|
Material | Monofilament Polypropylene |
Weight | ~82 g/m² |
Thickness | ~0.48 mm |
Pore Size | ~0.8 mm |
Flexural Rigidity | Lower (185–300 mg·cm) than traditional meshes (400–600) |
Transparency | High — allows visualization of underlying tissue |
Edge Finish | Laser-sealed to prevent fraying |
Sterilization | Ethylene oxide |
Indications | Various hernia repairs and prophylactic reinforcement |
Contraindications | Infected/contaminated areas, growing pediatric use |
